Nickel Alloys Alloy K500 Industrial Valves Overview
Zeon Exports supplies Nickel Alloy K500 (Monel, UNS N05500) industrial valves – ball, gate, globe and check types – an age-hardenable nickel-copper alloy combining Monel 400's corrosion resistance with roughly triple the yield strength.
Nickel Alloy K500 (Monel) Industrial Valves control and isolate flow in seawater and chemical process lines where high strength and corrosion resistance are both required. Precipitation hardened through aluminum and titanium additions, it retains the corrosion resistance of Alloy 400 while offering roughly triple the yield strength and double the tensile strength.
- Age-hardened via aluminum and titanium for very high strength
- Non-magnetic to as low as –101°C (–150°F)
- EN 10204 3.1 certified, export-ready worldwide
Quick Specifications of Nickel Alloys Alloy K500 Industrial Valves
Nickel Alloy K500 (Monel) Industrial Valves are produced to internationally recognized specifications.
| Field | Detail |
|---|---|
| Material/Grade | Nickel Alloy K500 (Monel) |
| UNS | N05500 |
| DIN/Werkstoff Number | 2.4375 |
| Standards | Confirm applicable ASTM forging/casting standard on order |
| Form | Ball, Gate, Globe, Check Valves |
| Finish | As specified |
| Heat Treatment | Age Hardened |
| Certification | EN 10204 3.1 |
Equivalent Grades of Alloy K500
Alloy K500 (Monel) is recognized under several international designations below.
| UNS | DIN/Werkstoff Number | Common Trade Name |
|---|---|---|
| N05500 | 2.4375 | Monel K-500 |
Chemical Composition of Nickel Alloy K500
Composition per UNS N05500; exact limits can vary slightly by specification and heat.
| Element | Composition (%) |
|---|---|
| Nickel (Ni), min | 63.0 |
| Copper (Cu) | 27.0 – 33.0 |
| Aluminum (Al) | 2.30 – 3.15 |
| Titanium (Ti) | 0.35 – 0.85 |
Physical Properties of Nickel Alloys Alloy K500
Physical properties for Alloy K500, confirmed against manufacturer data.
| Property | Value |
|---|---|
| Density | 8.44 g/cm3 |
| Magnetic Behaviour | Non-magnetic to about –101°C (–150°F) |
Mechanical Properties of Nickel Alloys Alloy K500 Industrial Valves
Typical age-hardened minimums; confirm exact minimums against the applicable standard.
| Property | Minimum Value |
|---|---|
| Tensile Strength | 1000 MPa (145 ksi) |
| Yield Strength (0.2% offset) | 690 MPa (100 ksi) |
| Elongation | 20% |
| Condition | Age Hardened |
Corrosion Resistance of Nickel Alloys Alloy K500
Nickel Alloy K500 Industrial Valves retain Alloy 400's corrosion profile while adding significant strength.
- Seawater resistance: excellent resistance to seawater and marine atmospheres, ideal for offshore process lines.
- Acid resistance: strong resistance to hydrofluoric acid and reducing acids, inherited from the base Alloy 400 chemistry.
- Non-magnetic: remains virtually non-magnetic down to –101°C, useful near magnetic-sensitive equipment.
Heat Resistance of Nickel Alloys Alloy K500
Nickel Alloy K500 valves maintain their strength up to roughly 649°C (1,200°F) and stay ductile and tough at low sub-zero temperatures. Confirm exact service limits against the governing standard and application before specifying.
Key Properties of Nickel Alloys Alloy K500 Industrial Valves
Beyond corrosion and heat performance, Alloy K500 valves offer these additional properties.
- Roughly triple the yield strength of Alloy 400
- Good galling and wear resistance versus austenitic bolting
- Age hardened after cold working for maximum strength
- Good toughness maintained into low sub-zero temperatures
Benefits of Nickel Alloys Alloy K500 Industrial Valves
Choosing Alloy K500 valves from Zeon Exports delivers measurable advantages for your project.
- High strength combined with proven Monel-family corrosion resistance
- Full MTC 3.1 documentation for project QA/QC requirements
- Multiple valve types and end connections to match project specs
- Reliable bulk supply with consistent ready stock
- Competitive export pricing for large industrial orders
- Fast dispatch to global project sites and ports
Related Products
Explore related Nickel Alloys products from Zeon Exports.
Request a Quote for Nickel Alloys Alloy K500 Industrial Valves
Ready to source Nickel Alloy K500 (Monel) Industrial Valves? Share your valve type, size and quantity requirements and our team will respond with a quote.
Call: +91 98205 33105
Email: info@zeonexports.com
Website: www.zeonexports.com
Address: A-7/9, Saboo Building, Ardeshir Dady Cross Lane, Cawasji Patel Tank Road, Mumbai – 400004
Frequently Asked Questions About Nickel Alloys Alloy K500 Industrial Valves
Common questions about Nickel Alloy K500 (Monel) Industrial Valves, answered below.
Q1: What is Nickel Alloy K500 (Monel)?
Ans. Monel K-500 (UNS N05500) is an age-hardenable nickel-copper alloy with roughly triple the yield strength of Alloy 400.
Q2: Which valve types are available in Alloy K500?
Ans. We supply ball, gate, globe and check valves with Alloy K500 bodies and trim.
Q3: Is Alloy K500 magnetic?
Ans. No, Alloy K500 is virtually non-magnetic, remaining so down to about –101°C (–150°F).
Q4: What is the maximum service temperature?
Ans. Alloy K500 maintains its strength up to roughly 649°C (1,200°F); confirm exact limits against your design code.
Q5: Is Alloy K500 suitable for seawater service?
Ans. Yes, Alloy K500 has excellent resistance to seawater, widely used in offshore process lines.
Q6: What certification is provided with orders?
Ans. Every order ships with EN 10204 3.1 mill test certificates confirming grade, heat and dimensions.
Q7: Does Zeon Exports supply custom valve sizes?
Ans. Yes, valves are available in custom sizes and end connections on request for bulk industrial orders.
Q8: What standards apply to Alloy K500 valves?
Ans. Valves are manufactured per applicable ASTM forging/casting standards, certified to EN 10204 3.1 mill test certificates.
