Nickel Alloys Alloy 20 Structural Profiles Overview
Zeon Exports supplies Nickel Alloy 20 (UNS N08020) structural profiles – angles, channels and beams – a nickel-iron-chromium alloy with copper and molybdenum additions developed for maximum resistance to sulfuric acid.
Nickel Alloy 20 Structural Profiles form load-bearing frames for chemical, pharmaceutical and food processing facilities handling sulfuric acid, phosphoric acid and other aggressive chemical process streams. Its nickel-iron-chromium base with copper and molybdenum gives outstanding resistance to acid attack, while niobium stabilization prevents sensitization and intergranular corrosion after welding.
- Niobium-stabilized against sensitization and weld-zone corrosion
- Tensile ≥551 MPa, yield ≥241 MPa in the annealed condition
- EN 10204 3.1 certified, export-ready worldwide
Quick Specifications of Nickel Alloys Alloy 20 Structural Profiles
Nickel Alloy 20 Structural Profiles are produced to internationally recognized specifications.
| Field | Detail |
|---|---|
| Material/Grade | Nickel Alloy 20 |
| UNS | N08020 |
| DIN/Werkstoff Number | 2.4660 |
| Form | Angles, Channels, Beams |
| Finish | Hot rolled, ground |
| Heat Treatment | Annealed |
| Certification | EN 10204 3.1 |
Equivalent Grades of Alloy 20
Alloy 20 is recognized under several international designations below.
| UNS | DIN/Werkstoff Number | Common Trade Name |
|---|---|---|
| N08020 | 2.4660 | Carpenter 20 / Alloy 20Cb-3 |
Chemical Composition of Alloy 20
Composition for UNS N08020; exact limits can vary slightly by specification and heat.
| Element | Composition (%) |
|---|---|
| Nickel (Ni) | 32.0 – 38.0 |
| Chromium (Cr) | 19.0 – 21.0 |
| Molybdenum (Mo) | 2.0 – 3.0 |
| Copper (Cu) | 3.0 – 4.0 |
| Niobium (Nb), min–max | 8×C – 1.00 |
| Iron (Fe) | Balance |
Physical Properties of Nickel Alloys Alloy 20
Physical properties for Alloy 20, confirmed against manufacturer data.
| Property | Value |
|---|---|
| Density | ~8.08 g/cm3 (typical) |
| Magnetic Behaviour | Essentially non-magnetic |
Mechanical Properties of Nickel Alloys Alloy 20 Structural Profiles
Minimum mechanical properties for annealed UNS N08020.
| Property | Minimum Value |
|---|---|
| Tensile Strength | ≥551 MPa (80 ksi) |
| Yield Strength (0.2% offset) | ≥241 MPa (35 ksi) |
| Elongation | ≥30% |
| Condition | Annealed |
Corrosion Resistance of Nickel Alloys Alloy 20
Nickel Alloy 20 Structural Profiles were developed specifically for aggressive acid service.
- Acid resistance: copper and molybdenum give dual-mechanism protection against sulfuric acid attack.
- Pitting and crevice resistance: performs well in chloride-bearing and oxidizing salt environments.
- Weld-zone resistance: niobium stabilization prevents sensitization and intergranular corrosion after welding.
Heat Resistance of Nickel Alloys Alloy 20
Nickel Alloy 20 structural profiles have good mechanical properties at both ambient and moderately elevated temperatures, but are generally not selected for high-temperature structural service. Confirm exact service limits against the governing standard and application before specifying.
Key Properties of Nickel Alloys Alloy 20 Structural Profiles
Beyond corrosion and heat performance, Alloy 20 profiles offer these additional properties.
- Readily fabricable, well suited to chemical processing equipment
- Good weldability without post-weld sensitization risk
- Good strength and toughness at ambient temperatures
- Widely used across chemical, pharmaceutical and food processing
Benefits of Nickel Alloys Alloy 20 Structural Profiles
Choosing Alloy 20 profiles from Zeon Exports delivers measurable advantages for your project.
- Purpose-built resistance to sulfuric acid where stainless falls short
- Full MTC 3.1 documentation for project QA/QC requirements
- Multiple profile shapes and sizes to match project specs
- Reliable bulk supply with consistent ready stock
- Competitive export pricing for large industrial orders
- Fast dispatch to global project sites and ports
Related Products
Explore related Nickel Alloys products from Zeon Exports.
Request a Quote for Nickel Alloys Alloy 20 Structural Profiles
Ready to source Nickel Alloy 20 Structural Profiles? Share your profile type, size and quantity requirements and our team will respond with a quote.
Call: +91 98205 33105
Email: info@zeonexports.com
Website: www.zeonexports.com
Address: A-7/9, Saboo Building, Ardeshir Dady Cross Lane, Cawasji Patel Tank Road, Mumbai – 400004
Frequently Asked Questions About Nickel Alloys Alloy 20 Structural Profiles
Common questions about Nickel Alloy 20 Structural Profiles, answered below.
Q1: What is Nickel Alloy 20?
Ans. Alloy 20 (UNS N08020) is a nickel-iron-chromium alloy with copper and molybdenum additions developed for sulfuric acid resistance.
Q2: Which profile shapes are available in Alloy 20?
Ans. We supply angles, channels and beams across standard structural sizes.
Q3: Is Alloy 20 resistant to sulfuric acid?
Ans. Yes, Alloy 20 was developed specifically for maximum resistance to sulfuric acid across a wide range of concentrations.
Q4: Is Alloy 20 magnetic?
Ans. Alloy 20 is essentially non-magnetic, being an austenitic nickel-iron-chromium alloy.
Q5: Does Alloy 20 resist sensitization after welding?
Ans. Yes, niobium stabilization prevents sensitization and intergranular corrosion in the weld zone.
Q6: What certification is provided with orders?
Ans. Every order ships with EN 10204 3.1 mill test certificates confirming grade, heat and dimensions.
Q7: Does Zeon Exports supply custom profile sizes?
Ans. Yes, profiles are available cut-to-size and in custom dimensions on request for bulk industrial orders.
Q8: How is Alloy 20 different from Alloy C276?
Ans. Alloy 20 targets sulfuric acid service specifically, while Alloy C276 covers a much broader range of both oxidizing and reducing media.
